Tehnicki Opis
Engine Type horizontal, single-cylinder, two-strokes, air-cooled, with lamellar induction timing system
Bore and Stroke 40 x 39.2 mm
Displacement 50 cc
Compression Ratio 12.8:1
Carburettor Dellorto PH BN 12
Ignition electronic
Start-up electric and kick starter
Generator magneto flywheel 85W-12W
Lubrication separate mixer with mechanical pump Gearbox automatic convertor
Clutch automatic, centrifugal
Primary transmission with trapezoidal belt
End transmission adapter with gears
Frame split single-cradle in high tensile tubular steel
Suspensions front: telehydraulic fork assembled on misaligned steering sleeve.
rear: engine functions as oscillating fork, linked to the frame by connecting rod assemblies supported by two radial silent blocks and one axial silent block with progressive damping.
Brakes: stainless steel disc brakes Ć 190 mm. with racing caliper and two opposed pistons Ć 32 mm.
Tyres front and rear 130/60 x 13"
Rims five spokes, light alloy
front and rear: 3.50 x 13"
Dimensions maximum length 1790 mm.
maximum width 720 mm.
maximum height 1160 mm.
saddle height 815 mm.
wheel base 1250 mm.
Dry Weight 99 kg.
Fuel tank Capacity 8 litres (reserve 2 litres)
|
|
